The Bobcat E35 is a compact excavator known for its versatility and performance in tight spaces. It features a zero-tail swing design‚ powerful digging capabilities‚ and easy maintenance access. Operators appreciate its comfortable cab and intuitive controls‚ making it ideal for demanding jobsites. With a proven track record‚ the E35 is a reliable choice for construction and landscaping projects.
Overview of the Bobcat E35 Model
The Bobcat E35 is a compact excavator designed for versatility and performance in tight spaces. Weighing approximately 7‚699 lbs‚ it combines a robust design with precise control‚ making it ideal for urban construction and landscaping projects. Its zero-tail swing feature enhances maneuverability‚ while the in-track frame ensures stability and reduced footprint. The E35 is powered by a reliable diesel engine‚ delivering 24.8 horsepower and a maximum governed RPM of 2‚550. With a focus on operator comfort‚ it features an ergonomic cab and intuitive controls. The excavator is also designed for easy maintenance‚ with accessible critical components. Its compact size and powerful digging capabilities make it a popular choice for demanding jobsites‚ ensuring efficiency and productivity in various applications.
Key Specifications of the Bobcat E35
The Bobcat E35 features a 24.8 HP engine‚ operating weight of 7‚699 lbs‚ and a maximum governed RPM of 2‚550. It offers 4‚859 lbf arm digging force and 6‚968 lbf bucket digging force‚ with an auxiliary hydraulic flow of 12.7 gpm.
Engine Specifications
The Bobcat E35 is equipped with a 24.8 HP diesel engine‚ featuring a maximum governed RPM of 2‚550. This turbocharged engine ensures efficient performance across various tasks‚ delivering reliable power for digging and lifting. The engine meets Tier 4 emissions standards‚ making it environmentally friendly. With a fuel tank capacity of 13.7 gallons‚ the E35 offers extended operation without frequent refueling. Its compact design and robust construction make it suitable for demanding jobsites‚ providing consistent power for both heavy-duty and precise operations. The engine’s durability and efficiency contribute to the excavator’s overall productivity‚ making it a trusted choice for professionals in construction and landscaping industries.
Operating Weight and Dimensions
The Bobcat E35 has an operating weight of 7‚699 lbs (3.5 tons)‚ making it ideal for jobsites with weight restrictions. Its compact dimensions include a transport length of 4.82 meters (15.8 feet) and a width of 1.88 meters (6.2 feet). The blade height is 350 mm (13.8 inches)‚ and the clearance of the upper structure to the ground is 537 mm (21.1 inches). The zero-tail swing design enhances maneuverability in tight spaces. The track width is 300 mm (11.8 inches)‚ contributing to its stability and ability to work in confined areas. These dimensions ensure the E35 can easily navigate and operate on various construction and landscaping projects without compromising performance. Its compact footprint is a key advantage for urban and restricted-site applications.
Performance Metrics
The Bobcat E35 delivers impressive performance with a rated lift capacity of 3‚232 lbs (1‚467 kg)‚ enabling efficient material handling. Its arm digging force of 4‚859 lbf (21.7 kN) and bucket digging force of 6‚968 lbf (31 kN) ensure strong excavation capabilities. The excavator achieves a maximum digging depth of 10 feet 3 inches (3.12 meters) and a maximum reach of 17 feet 3 inches (5.26 meters). Travel speeds are up to 2.9 mph (4.7 km/h) in high gear and 1.6 mph (2.6 km/h) in low gear‚ providing efficient movement on the jobsite. These performance metrics make the E35 suitable for a wide range of tasks‚ from digging trenches to lifting heavy materials‚ ensuring productivity and reliability in various applications. Its balanced power and precision control enhance overall operational efficiency.
Design and Build Features
The Bobcat E35 features a zero-tail swing design‚ allowing unrestricted rotation in tight spaces. Its in-track frame enhances maneuverability‚ while easy maintenance access simplifies routine servicing‚ ensuring durability and productivity.
Zero-Tail Swing Design
The Bobcat E35’s zero-tail swing design ensures unrestricted rotation‚ making it ideal for confined spaces. This feature eliminates overhang during turns‚ reducing the risk of damage to nearby structures. Operators can work confidently in tight areas‚ such as urban construction sites or landscaping projects‚ without compromising performance. The zero-tail swing also enhances safety by allowing clear visibility and precise control. This innovative design contributes to the E35’s reputation as a versatile and efficient compact excavator‚ capable of handling a wide range of tasks with ease and precision. The zero-tail swing is a key factor in the E35’s popularity among professionals who need reliability and adaptability in challenging environments.
In-Track Frame and Maneuverability
The Bobcat E35 features an in-track frame design‚ which provides a compact footprint and exceptional maneuverability. This design allows the excavator to operate efficiently in tight spaces while maintaining stability. The undercarriage is engineered for smooth travel and precise control‚ making it ideal for navigating challenging jobsites. With a track width of 300 mm‚ the E35 ensures minimal ground disturbance and easy transportation between locations. Its compact dimensions and agile movement enable operators to handle tasks in confined areas without sacrificing performance. The in-track frame also enhances the machine’s portability‚ allowing it to be easily loaded onto trailers for transport. This feature‚ combined with its zero-tail swing‚ makes the E35 a highly versatile choice for construction and landscaping projects requiring precision and adaptability.
Maintenance Access and Serviceability
The Bobcat E35 is designed with ease of maintenance in mind‚ ensuring minimal downtime and reducing service complexity. Key components are strategically located for easy access‚ including a tilting cab that provides unobstructed access to the engine and hydraulic systems. The machine features wide-opening service panels‚ allowing operators to perform routine checks and repairs efficiently. A centralized grease point simplifies lubrication of pivot pins‚ reducing maintenance time. Additionally‚ the E35’s design ensures quick access to the battery‚ air filter‚ and fuel tank‚ making daily inspections straightforward. These thoughtful design elements enhance serviceability‚ ensuring the excavator remains operational and productive on demanding jobsites. Regular maintenance is streamlined‚ helping operators maintain peak performance and extend the machine’s lifespan.
Hydraulic and Digging Capabilities
The Bobcat E35 excels in hydraulic performance‚ offering precise control and robust digging power. Its auxiliary hydraulic flow enhances attachment versatility‚ while the bucket and arm provide strong digging forces for efficient earthmoving tasks.
Auxiliary Hydraulic Flow
The Bobcat E35 offers an auxiliary hydraulic flow system‚ designed to enhance versatility by enabling the use of various attachments. This feature allows for precise control over hydraulic-powered tools‚ ensuring efficient operation. Operators can easily switch between different attachments‚ optimizing productivity on diverse tasks. The system’s reliability and adaptability make it suitable for demanding jobsites‚ where multiple functions are often required. Additionally‚ the E35’s hydraulic flow is optimized to minimize energy waste‚ providing consistent performance across all operations. This capability‚ combined with the excavator’s compact design‚ makes it an ideal choice for projects requiring both power and agility.
Bucket and Digging Force
The Bobcat E35 excavator delivers impressive digging performance with a maximum arm digging force of 4‚859 lbf and a bucket digging force of 6‚968 lbf. These forces enable efficient excavation in various soil types and conditions. The machine supports a range of bucket sizes‚ from 330 mm to 610 mm‚ allowing operators to tackle tasks like trenching and material handling with precision. The robust design of the bucket and arm ensures durability‚ even in demanding environments. Additionally‚ the E35’s hydraulic system provides smooth control‚ making it easier to manage heavy loads and achieve consistent results. Whether digging deep trenches or lifting materials‚ the E35’s digging force and bucket versatility make it a reliable choice for construction and landscaping projects.
Dimensions and Transport Requirements
The Bobcat E35 has a transport length of 4.82 meters and a width of 1.99 meters‚ making it easy to transport between job sites. Its undercarriage measures 300 mm wide‚ and the blade height is 350 mm‚ ensuring stable transport and maneuverability. These dimensions allow the E35 to fit into tight spaces while maintaining operational efficiency. The compact size and balanced design simplify logistics‚ ensuring the excavator arrives ready to work. The machine’s transport requirements are minimal‚ making it a practical choice for various construction and landscaping projects. Proper securing during transport is essential to ensure safety and prevent damage. Always follow manufacturer guidelines for transportation.
Transport Length and Width
The Bobcat E35 excavator has a transport length of 4.82 meters and a width of 1.99 meters‚ making it suitable for easy transportation between job sites. Its compact dimensions ensure it can maneuver through tight spaces without compromising functionality. The machine’s transport length is measured from the tip of the bucket to the rear of the cab‚ while the width includes the tracks and undercarriage. These measurements are crucial for planning transportation logistics‚ ensuring the excavator can be safely loaded onto trailers or trucks. The E35’s transport width remains consistent with its operational width‚ allowing it to navigate through standard gateways and narrow construction sites. This design ensures minimal disruption during transportation and setup‚ enhancing overall efficiency for operators. Proper securing during transport is essential to prevent damage and ensure safety. Always refer to the manufacturer’s guidelines for specific transport requirements and precautions.
Undercarriage and Blade Dimensions
The Bobcat E35 excavator features a robust undercarriage designed for stability and durability. The track width is 300 mm‚ providing a solid base for operation on various terrains. The blade dimensions include a blade height of 350 mm and a blade width that complements the machine’s overall footprint. These measurements ensure effective ground clearance and digging performance while maintaining maneuverability. The undercarriage is built to withstand heavy-duty applications‚ with components designed for longevity and minimal wear. The blade’s compact dimensions allow for precise excavation in confined spaces‚ making it ideal for urban construction sites. Additionally‚ the undercarriage’s design facilitates easy maintenance‚ with accessible components for routine checks. These dimensions also contribute to the machine’s transportability‚ ensuring it can be efficiently moved between locations without exceeding standard trailer widths. The E35’s undercarriage and blade dimensions strikes a balance between performance and practicality‚ enhancing its versatility on the job site.
